Break out of the box and expand your road riding adventures. From smooth pavement to bumpy backroads, this ultra-capable road bike has built-in compliance and high-volume tires, so you can ride any road with confidence and control.
Balanced Road Geometry
Frame is specifically engineered to produce a balanced, all-rounder feel that blends confident rider positioning with agile cornering and acceleration.
Smooth Ride Quality
Innovative D-Fuse seatpost reduces road shocks and vibrations, and a Giant WheelSystem lets you run tubeless tires up to 38mm for a smoother ride quality and reduced risk of flats.
Total Control
Seamless disc brake integration, including flat mounts and 12mm front and rear thru-axles, produces more consistent braking power for better control, even in wet weather and on rough roads.
Specifications
Frame
ALUXX-grade aluminum, 12x142mm thru-axle, disc
Fork
Advanced-grade composite, full-composite OverDrive steerer, 12x100mm thru-axle, disc
Handlebar
Giant Connect
Grips
Velo cork tape with gel
Stem
Giant Sport
Seatpost
Giant D-Fuse, composite, 14mm offset
Saddle
Giant Approach
Pedals
Platform
Shifters
Shimano Tiagra
Front Derailleur
Shimano Tiagra FD-4700
Rear Derailleur
Shimano Tiagra RD-4700 GS
Brakes
Shimano Tiagra hydraulic
Giant MPH rotors [F] 160mm, [R] 160mm
Brake Levers
Shimano Tiagra
Cassette
Shimano Tiagra, 10-speed, 11x34
Chain
KMC X10
Crankset
Shimano Tiagra, 34/50 XS, S: 170mm, M, M/L: 172.5mm, L, XL: 175mm
Bottom Bracket
Cartridge
Rims
Giant S-R2 Disc wheelset, alloy, [F] 25mm, [R] 25mm
Hubs
Giant alloy, 12mm thru-axle
Spokes
Sapim
Tires
Giant Gavia Fondo 2, tubeless, 700x32c (34mm)
Extras
Fender mount, tubeless prepared, 38mm max tire size
* Specifications are subject to change without notice
Geometry
| XS | S | M | M/L | L | XL | ||
|---|---|---|---|---|---|---|---|
| A | Reach | 371 | 375 | 380 | 383 | 392 | 400 |
| B | Stack | 539 | 559 | 574 | 595 | 614 | 638 |
| C | Head Tube Angle | 71.5° | 71.8° | 72.0° | 72.5° | 72.5° | 72.5° |
| D | Bottom Bracket Drop | 80 | 80 | 80 | 80 | 80 | 80 |
| E | Wheelbase | 994 | 1003 | 1011 | 1015 | 1031 | 1046 |
| F | Chain Stay Length | 422 | 422 | 422 | 422 | 422 | 422 |
| G | Head Tube Length | 115 | 135 | 150 | 170 | 190 | 215 |
| H | Top Tube Length | 515 | 535 | 550 | 565 | 580 | 595 |
| I | Seat Tube Angle | 75.0° | 74.0° | 73.5° | 73.0° | 73.0° | 73.0° |
| J | Stand Over Height | 727 | 759 | 783 | 810 | 829 | 856 |
*All measurements in degrees or millimetres
Sizing Guide
| Size | Height | |
|---|---|---|
| Imperial | Metric | |
| XS | 5'2" - 5'7" | 157 - 169cm |
| S | 5'5" - 5'9" | 165 - 175cm |
| M | 5'7" - 5'11" | 171 - 181cm |
| M/L | 5'10" - 6'2" | 177 - 187cm |
| L | 6'0" - 6'4" | 183 - 193cm |
| XL | 6'2" - 6'6" | 189 - 199cm |
The sizing chart is a great place to start when picking your next bike but everyone will fit a bike a bit differently. Your torso, arm, and leg lengths all play into what size of bike you may need. Plus, there's your own personal preference.
We always recommend swinging by the shop and taking the bike that you're looking for a spin to see how it feels. If you're unable to come by, looking at the geometry of your current bike and comparing it is a good place to start. If you have any further questions, our customer service team is there to help.
