Specifications
Please note - specifications subject to change without prior notice.| FRAME | Series 3 6061 Aluminum, 130mm Travel, MultiTrac Suspension Platform, 148x12mm Boost Thru-Axle, 73mm Threaded BB w/ ISCG05 Tabs |
| FRONT SUSPENSION | Marzocchi Bomber Z2, Rail Damper with Sweep Adjustment, 140mm Travel, Kabolt Bolt-On Axle, 44mm Offset |
| REAR SUSPENSION | RockShox Deluxe Select RT, Debonair Air Sleeve, Rebound Adjustment, Custom Tune, 210x55mm, M8x25mm Hardware |
| RIMS | Marin, Double Wall Alloy, 29mm Inner, Pinned Joint, Disc Specific, 32H, Tubeless Compatible |
| HUB, REAR | Shimano FH-TC500, 148x12mm, Disc, HG Freehub Body |
| HUB, FRONT | Shimano HF-TC500, 110x15mm, Centerlock, 32H |
| SPOKES | 14g Black Stainless Steel |
| TIRES | Vee Tire Co. Snap WCE 2.35", Top 40 Compound, GXE Core, 90 TPI, Tubeless compatible |
| DERAILLEUR, REAR | Shimano Deore, 12-Speed, SGS |
| DERAILLEUR, FRONT | - |
| SHIFT LEVER | Shimano Deore, 12-Speed, SL-M6100-R |
| CRANKSET | FSA Comet, Modular 1x, 32T Direct Mount Chainring, MegaTooth Technology, Boost Spacing |
| BOTTOM BRACKET | External Sealed Cartridge Bearing |
| CHAIN | KMC X-12 Silver and Black |
| CASSETTE | SunRace, 12-Speed, 11-51T |
| BRAKE, FRONT | Tektro HD-M535 Hydraulic Disc, 180mm Rotor |
| BRAKE, REAR | Tektro HD-M535 Hydraulic Disc, 180mm Rotor |
| BRAKE LEVERS | Tektro HD-M535 Hydraulic |
| HANDLEBAR | Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5Âş Up, 9Âş Back |
| STEM | Marin 3D Forged Alloy, 35mm |
| GRIPS | Marin Grizzly Lock On |
| HEADSET | FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2” |
| SEATPOST | X-Fusion Manic, 1x Composite Remote, Size S 150mm Travel, Size MXL 170mm Travel, 30.9mm |
| SADDLE | Marin Speed Concept |
| PEDALS | - |
| EXTRAS | Bolt-On Thru-Axle
|
